NB ERGONOMIC H180 Dual Monitor Arm
Key Features:
- Dual gas spring monitor arm — single vertical pole, side-by-side configuration
- Screen size: 17–27 inches per arm | Load: 2–9KG (4.4–19.8 lbs) per arm
- Independent gas spring per arm — smooth single-finger height adjustment
- Tilt +85°/-30°, swivel ±90°, rotation 360° per arm
- Height adjustment: 260mm (9.8″) per arm
- Max arm extension from pole: 560mm (22.1″)
- Max VESA center height from desk: 640mm (25.2″)
- Max horizontal spread (VESA to VESA): 885mm (34.8″)
- Pole height: 430mm (16.9″) | Pole diameter: 35mm
- Portrait & landscape mode supported on each arm
- VESA 75×75mm / 100×100mm compatible | VESA plate: 118×118mm
- Integrated cable management through both arms and pole
- C-Clamp (25–80mm) + Grommet (20–90mm) — both included
- Single base — one mounting point for both arms
₨ 8,999.00 ₨ 12,999.00
NB ERGONOMIC H180 — Gas Spring Dual Monitor Arm for Two 17–27 Inch Monitors
The NB ERGONOMIC H180 is a full-motion dual monitor arm built for home office users, gamers, and professionals who run two screens from a single shared base. Both arms extend outward from one central vertical pole — requiring only one mounting point on your desk while giving each screen its own fully independent gas spring, tilt, swivel, and rotation control.
In addition, the NB ERGONOMIC H180 supports monitors from 17 to 27 inches with up to 9KG load per arm. As a result, it covers the vast majority of standard gaming and office monitors. Furthermore, with a max horizontal spread of 885mm (34.8″) between VESA centers, it comfortably accommodates two 27-inch monitors side by side. Check out our full range of Monitor Arms at Backseat Gaming, or learn more on the NB ERGONOMIC official website.
Who Should Buy the NB ERGONOMIC H180?
- Home office users running a primary and secondary monitor side by side
- Gamers who want a clean dual-monitor setup with minimal desk footprint
- Professionals who need independent control over each screen’s height, tilt, and angle
- Users who want smooth, effortless height adjustment on both monitors simultaneously
- Anyone upgrading from two separate monitor stands to a single unified dual-arm solution
NB H180 — Precision Gas Spring on Both Arms
Each arm of the NB ERGONOMIC H180 uses its own independent ultra-precision gas strut. In addition, once tension is set to match your monitor’s weight, height adjustment is smooth and effortless — simply push or pull the screen to the desired position and it holds instantly. As a result, both screens can be repositioned with a single finger without resistance or wobble.
The tension is manually adjustable via a screw on each arm. Furthermore, always adjust with the monitor mounted — do not adjust the tension screw without a monitor on the arm.
NB H180 — Independent Full Motion on Both Arms
Each arm on the NB ERGONOMIC H180 operates completely independently with a full range of motion. In addition to gas spring height adjustment, each arm tilts, swivels, and rotates without affecting the other. As a result, you can set one screen in portrait and the other in landscape, angle each monitor independently, and position them at different heights from the same pole.
Single Vertical Pole — Minimal Desk Footprint
Both arms share a single 35mm vertical pole mounted at one point on your desk. In addition, both arms extend outward from the same base — meaning only one clamp or grommet is needed to support the full dual-monitor setup. As a result, the H180 takes up the smallest possible desk footprint for a dual-arm gas spring solution, freeing up valuable surface space on either side.
VESA Compatible — Fits Most 17–27 Inch Monitors
The NB ERGONOMIC H180 is compatible with VESA 75×75mm and 100×100mm mounting patterns — the two most common VESA standards on the market. In addition, the VESA plate measures 118×118mm. However, monitors with recessed VESA holes may require longer screws or spacers not included in the box. Furthermore, curved monitors should be checked for VESA plate compatibility before purchase.
Dual Installation — C-Clamp or Grommet
Both installation methods are included in the box. In addition, the single shared base means only one mounting action is required — not two — making setup faster and cleaner than separate single-arm solutions.
- C-Clamp — clamps to the desk edge, no drilling required, fits desk thickness 25–80mm (1″–3.1″)
- Grommet — through an existing desk hole, fits desk thickness 20–90mm (0.8″–3.5″)
Built-In Cable Management
The NB ERGONOMIC H180 features integrated cable management channels running through both arms and the central pole. In addition, all monitor cables are routed neatly inside the structure from screen to base. As a result, your desk stays clean and organized with no visible loose cable runs.
Technical Specifications
| Model | NB ERGONOMIC H180 |
| Configuration | Dual Arm — Single Vertical Pole, Side-by-Side |
| Screen Size (per arm) | 17–27 Inches |
| Load Capacity (per arm) | 2–9KG (4.4–19.8 lbs) |
| Tilt (per arm) | +85° / -30° |
| Swivel (per arm) | ±90° |
| Rotation (per arm) | 360° (Landscape / Portrait) |
| Height Adjustment (per arm) | 260mm (9.8″) |
| Max Arm Extension (from pole) | 560mm (22.1″) |
| Max Height (VESA center to desk) | 640mm (25.2″) |
| Max Horizontal Spread (VESA to VESA) | 885mm (34.8″) |
| Pole Height | 430mm (16.9″) |
| Pole Diameter | 35mm |
| Base Footprint | 120mm (4.7″) from pole |
| VESA Compatibility | 75×75mm / 100×100mm |
| VESA Plate Size | 118×118mm |
| Spring Type | Gas Spring (independent per arm) |
| Cable Management | Integrated — through arms and pole |
| Installation | C-Clamp (25–80mm) / Grommet (20–90mm) — both included |
| Color | Black |
Frequently Asked Questions
What is the difference between the NB H180 and the NB F160?
Both are dual-arm single-base monitor arms with gas springs, but they differ in design. The F160 supports 17–27 inch monitors and uses two arms at the same base level. The H180 also supports 17–27 inch monitors from a single vertical pole with both arms extending side by side. However, the H180 offers a taller pole height of 430mm and a max VESA height of 640mm — giving more vertical positioning range. Furthermore, the H180’s single vertical pole design is slightly more compact in base footprint than the F160.
Can both arms be adjusted independently on the NB H180?
Yes. Each arm has its own independent gas spring and operates completely independently. As a result, you can set each screen to a different height, tilt, and angle without affecting the other arm.
Does the NB H180 support portrait mode?
Yes. Each VESA head rotates 360°, allowing full portrait and landscape switching on either or both arms independently.
Can I use two different sized monitors on the NB H180?
Yes, as long as both monitors are between 17–27 inches and within 2–9KG per arm. Furthermore, VESA compatibility (75×75mm or 100×100mm) should be verified for both monitors before mounting.
Do I need to drill my desk to install the NB H180?
No. The C-clamp method requires no drilling and clamps securely to desks 25–80mm thick. However, if you prefer a cleaner installation, the grommet method uses an existing desk hole. Both hardware sets are included in the box.
My monitor has recessed VESA holes — will it fit?
The VESA plate is 118×118mm. For recessed VESA holes, you may need longer screws or spacers which are not included. In addition, curved monitors should be checked for VESA plate compatibility before purchase.
What is the price of NB ERGONOMIC H180 Dual Monitor Arm in Nepal?
The price of NB ERGONOMIC H180 Dual Monitor Arm is NPR 12,999 only. You can purchase NB ERGONOMIC H180 Dual Monitor Arm from Backseatgaming.co with 1 year official warranty.
| Weight | 7 kg |
|---|
| Model | NB ERGONOMIC H180 |
| Configuration | Dual Arm — Single Vertical Pole, Side-by-Side |
| Screen Size (per arm) | 17–27 Inches |
| Load Capacity (per arm) | 2–9KG (4.4–19.8 lbs) |
| Tilt (per arm) | +85° / -30° |
| Swivel (per arm) | ±90° |
| Rotation (per arm) | 360° (Landscape / Portrait) |
| Height Adjustment (per arm) | 260mm (9.8″) |
| Max Arm Extension (from pole) | 560mm (22.1″) |
| Max Height (VESA center to desk) | 640mm (25.2″) |
| Max Horizontal Spread (VESA to VESA) | 885mm (34.8″) |
| Pole Height | 430mm (16.9″) |
| Pole Diameter | 35mm |
| Base Footprint | 120mm (4.7″) from pole |
| VESA Compatibility | 75×75mm / 100×100mm |
| VESA Plate Size | 118×118mm |
| Spring Type | Gas Spring (independent per arm) |
| Cable Management | Integrated — through arms and pole |
| Installation | C-Clamp (25–80mm) / Grommet (20–90mm) — both included |
| Color | Black |
